CABLE＆配線図
| SPケーブル | ||
|---|---|---|
| POWER-AMP〜FRONT-SP (FL/FR) | MIT | T2 Bi-Wire |
| POWER-AMP〜CENTER-SP (C) | MIT | T3S×2本 (Bi-Wire接続) |
| POWER-AMP〜SURROUND-SP (SL/SR/SB) | CANARE-linlinさん特製 | 4S11G |
| インターコネクトケーブル | ||
| PRE-AMP〜POWER-AMP | WIREWORLD | ECLIPSE 5 (XLR) |
| PRE-AMP〜D/A-CONVERTER | WIREWORLD | ECLIPSE 3+ (XLR) |
| PRE-AMP〜CS-PCM | WIREWORLD | POLARIS 3 (XLR) |
| AV-PRE〜PRE-AMP | WIREWORLD | ECLIPSE 3+ (XLR) |
| AV-PRE〜POWER-AMP | WIREWORLD | ECLIPSE 3+ (XLR) |
| AV-PRE〜SUB-WOOFER | ORTOFON | SWC-1180 (NEUTRIK製 XLR 改) |
| TV〜VCR-1 (D-VHS) | SPACE＆TIME | Prism55 |
| デジタルケーブル | ||
| CD-TRANSPORT〜D/A-CONVERTER | NBS | MONITOR 0×2本 (DUAL AES/EBU) |
| CS-PCM〜D/D-CONVERTER | AUDIO QUEST | VSD-2 |
| D/D-CONVERTER〜D/A-CONVERTER | ZAOLLA | DCR5 |
| D/D-CONVERTER〜AV-PRE | KIMBER KABEL | OPT1 TOSLINK |
| AV-PRE〜BD/DVD-RECORDER | SAEC | EFF-2000 |
| AV-PRE〜DVD | KIMBER KABEL | DIGITAL X |
| AV-PRE〜PROJECTOR | SUPRA | HDMI-HDMI CABLE |
| クロックケーブル | ||
| CLOCK GENERATOR〜CD-TRANSPORT | OYAIDE | DB-510 (BNC 75Ω) |
| CLOCK GENERATOR〜D/A-CONVERTER | OYAIDE | DB-510 (BNC 75Ω) |
| CLOCK GENERATOR〜D/D-CONVERTER | OYAIDE | DB-510 (BNC 75Ω) |
| CLOCK GENERATOR〜GPS TIME RECEIVER | L-COM | RG142B (BNC 50Ω) |
| ACケーブル | ||
| CD-TRANSPORT | NBS | MONITOR 1 |
| D/A-CONVERTER | NBS | MONITOR 0 |
| MASTER CLOCK GENERATOR | Synergistic Research | Reference A/C Master Coupler |
| D/D-CONVERTER | AET | GAIA |
| CS-PCM | AET | GAIA |
| AV-PRE | Synergistic Research | Reference A/C Master Coupler |
| PRE-AMP | Shunyata Research | Black Mamba |
| POWER-AMP (FL/FR) | CARDAS | GoldenReferencePower (20A) |
| POWER-AMP (SL/C/SR/SB) | CARDAS | GoldenReferencePower |
| SUB-WOOFER | CARDAS | GoldenPower |
| BD/DVD-RECORDER | OYAIDE | PA-22FX |
| DVD | AET | GAIA |
| HDMI-VIDEO SELECTOR | MIT | Z-CORD |
| PROJECTOR | 根岸通信 | ZAC1（fs仕様） |
| GPS TIME RECEIVER | 東日京三電線 | VVF 2C （EM-EEF） |
| DCケーブル | ||
| CD-TRANSPORT | ESOTERIC | 6N-DCP01 |
| 映像ケーブル | ||
| PROJECTOR〜AV-PRE | CANARE-linlinさん特製 | V5-5CFBマルチケーブル |
| PROJECTOR〜VCR-1 (D-VHS) | CANARE-linlinさん特製 | V3-5CFBマルチケーブル |
